Mini-Mac Applicator for 2.00mm (.079") Diameter Pin and Socket Terminals
CRIMP SPECIFICATIONS
Terminal Series No.
Bell mouth
mm In.
Cut-off Tab
mm In.
Conductor Brush
mm In.
35727
35728
Terminal Series No.
35727
35728
Bend up Bend down
Degree
Twist Roll
Degree
Punch Width (Ref)
Conductor Insulation
mm In. mm In.
2.30 .090 3.87 .152
2.30 .090 3.87 .152
Seam
Seam shall not be open
and no wire allowed out
of the crimping area
NOTE : Some of the specifications in these charts above are intentionally left blank due to the fact that the information
does not currently exist.
After crimping, the conductor profile should measure the following.
Terminal Series No.
Wire Size
Conductor
Crimp Height Crimp Width (Ref.)
Pull Force
Minimum
AWG
mm
2
mm In. mm In.
N Lb.
14
2.00
1.62-1.75 .065-.069
177.9 40.0
35727
35728
16
18
20
14
16
18
20
1.30
0.80
0.50
2.00
1.30
0.80
0.50
1.42-1.52 .056-.060
1.26-1.33 .0495-.0525
1.18-1.26 .0465-.0495
1.62-1.75 .065-.069
1.42-1.52 .056-.060
1.26-1.33 .0495-.0525
1.18-1.26 .0465-.0495
160.1 36.0
106.8 24.0
71.1 16.0
177.9 40.0
160.1 36.0
106.8 24.0
71.1 16.0
Pull Force should be measured with no influence from the insulation crimp.
The above specifications are guidelines to an optimum crimp.
Doc No. ATS-638923000
Revision: A
Release Date: 02-12-07
Revision Date: 02-12-07
UNCONTROLLED COPY
Page 2 of 5
